BU_002SWG Uninterruptible Power Supply Datasheet

Características

UPS de montagem múltipla, potência elevada, online

Método de alimentação em linha: fornecimento contínuo de energia face à quedas de tensão ou interrupções de energia instantâneas
Painel de operação 7seg fácil de operar
Várias comunicações I/F(USB/RS232C/sinal de I/O/Ethernet^*1)
Bloco de terminais de entrada/saída pré-instalado e sinal ON/OFF remoto externo para cliente FA
Baterias de substituição em funcionamento

*1. Tem de ser utilizado com a placa Ethernet opcional “SC20G2”

Especificações e info encomendas

Ordering information

Main body

Input voltage	Output voltage	Output current/capacity	Order code
220/230/240 VAC	220/230/240 VAC	1,000 VA/700 W	BU1002SWG
220/230/240 VAC	220/230/240 VAC	3,000 VA/2,100 W	BU3002SWG

Related products

Description	Applicable model	Order code
Replacement battery pack	BU1002SWG	BP100XSG
Replacement battery pack	BU3002SWG	BP150XSG
Mounting bracket	BU1002SWG	BUP100SG
Mounting bracket	BU3002SWG	BUP300SG
SNMP/Web card		SC20G2
Contact I/O card		SC08G2

Specifications

		BU1002SWG	BU3002SWG
Method	Operation method	Full-time inverter supply method
Method	Connectable devices	PC, display, and peripherals
Input	Rated input voltage	220/230/240 VAC
	Input voltage range	AC 185±4 to 276±4 V (with 85% or less connection load) AC 210±4 to 276±4 V (with 85% or more connection load)
	Frequency	50/60 Hz ± 4 Hz
	Maximum current	5.8 A	16 A
	Phase	Single-phase, two-wire
	Input plug shape	Schuko CEE 7/7 P	Schuko CEE 7/7 P
	Input protection	Reset-type overcurrent protection device
	Input protection capacity	10 A	20 A
Output	Allowable connection capacity3	1000 VA/700 W	3000 VA/2100 W
	Voltage (effective value)4	220 V mode AC 220 V ± 3% 230 V mode AC 230 V ± 3% 240 V mode AC 240 V ± 3%
	Peak voltage value (In Commercial Power Mode)	220 V mode: AC 310 V ± 6% 230 V mode: AC 324 V ± 6% 240 V mode: AC 338 V ± 6%
	Peak voltage value (In Battery Mode)	220 V mode: AC 310 V+6%/-10% 230 V mode: AC 324 V+6%/-10% 240 V mode: AC 338 V+6%/-12%
	Frequency	50/60 Hz ± 1 Hz
	Phase	Single-phase, two-wire
	Output waveform	Sine wave
	Waveform distortion rate (Rectified load, at rated output)	220V mode: 10% max. 230V mode: 10% max. 240V mode: 12% max.
	Number of output receptacles	IEC60320 C13: 3 pcs. Terminal block: 2 lines	IEC60320 C19: 1 pcs. C13: 5 pcs. Terminal block: 2 lines
	Power failure switching time	Uninterrupted
	Commercial direct shipment (switching time)	4 m sec. max.
	Backup time5	Minimum 5 minutes
Battery	Type	Compact sealed lead battery
	Sealed lead battery life expectancy	4 to 5 years (long operating life) *At ambient temperature of 20°C
	Battery capacity (V/Ah) (x Quantity)	12 VDC/7.2 Ah (× 3)	12 VDC/8 Ah (× 6)
	Charging time	8 hours6
Environment	Operating ambient temperature	0 to 40°C (during operation)/−15 to 50°C (during storage)
Environment	Operating ambient humidity	25 to 85% RH (during use)/10 to 90% RH (during storage)
Dimensions (W x H x D mm)		145 × 395 × 224 (±1) mm7	213 × 537 × 432 (±1) mm8
Weight of unit		Approx. 15.5 kg	Approx. 35 kg
Internal power consumption (max.)		50 W (100 W max.)	55 W (155 W max.)9
Noise regulation (compliance standard)		VCCI Class A
Safety standards / RoHS directive compliance		CE/RoHS compliance
Noise		50 dB max.	55 dB max.
Serial communication (RS-232C) (Interface)		D-Sub 9 pin
Serial communication (USB) (Interface)		B type10
Contact signal (Interface)		D-Sub 9 pin11

Backup time table

BU1002SWG

Connection capacity (W)	20	50	100	200	300	400	500	700	1000	1400
Backup time (Minutes)	180	120	60	35	20	15	10	5	−	−

BU3002SWG

Connection capacity (W)	200	400	600	800	1000	1200	1400	1600	1800	2000	2100
Backup time (Minutes)	92	46	30	20	15	12	10	8	7	5.5	5

Note: These backup times are for reference only. Times may vary according to battery life and external environmental conditions (temperature, etc.).

1. Has to be used with optional Ethernet card “SC20G2”

2. The standard UPS connection signal is NPN. To use a PNP connection, replace with “SC08G” included in the package.

3. Make sure that both the VA value and the W value of the load capacity connected to the UPS are within the range specified here.

4. Check the operation beforehand if the unit is used in any mode other than “220 VAC mode”. In some cases, the maximum voltage of output in Battery Mode may be lower than the maximum voltage in usual operation (commercial power supply).

5. The backup times shown here are for when rated load is connected, at 20°C, and for initial characteristics.

6. When an additional battery unit is connected, the charging time is 24 hours.

7. The height includes the 13 mm height of the rubber feet.

8. The height includes the 56 mm height of the casters.

9. 170 W max when and additional battery unit is connected.

10. USB or RS-232C either is available. (unusable at the same time)

11. The standard UPS connection signal is NPN. To use a PNP connection, replace with “SC08G” included in the package.

1. Has to be used with optional Ethernet card “SC20G2”

2. The standard UPS connection signal is NPN. To use a PNP connection, replace with “SC08G” included in the package.

3. Make sure that both the VA value and the W value of the load capacity connected to the UPS are within the range specified here.

5. The backup times shown here are for when rated load is connected, at 20°C, and for initial characteristics.

6. When an additional battery unit is connected, the charging time is 24 hours.

7. The height includes the 13 mm height of the rubber feet.

8. The height includes the 56 mm height of the casters.

9. 170 W max when and additional battery unit is connected.

10. USB or RS-232C either is available. (unusable at the same time)

11. The standard UPS connection signal is NPN. To use a PNP connection, replace with “SC08G” included in the package.

Software

Power Attendant Lite

Ao instalar o "Power Attendant Lite (PAL)" no seu computador ou sistema, pode desligar automaticamente todos os computadores (Windows) através da rede. Pode beneficiar do PAL em mais funções do que SSD.

Transfira o Power Attendant Lite

PowerAct Pro

Ao instalar o "PowerAct Pro Version 5" no seu computador ou sistema, pode desligar automaticamente computadores (Windows/Linux/Mac/Unix) através da rede. Foram adicionadas novas funcionalidades.

Transferir o software PowerAct Pro .

Simple Shutdown Software

O software Simple Shutdown (versão de fonte aberta) permite desligar automaticamente computadores e unidades UPS quando ocorre um problema de alimentação (falha de energia, etc.). Pode transferir este software gratuitamente. Ao utilizar este software e o seu código fonte, pode incorporar funções de encerramento automático quer o seu sistema seja Windows ou Linux.

Transferir o software Simple Shutdown .
